EBARA - Sump, Effluent, Sewage - DL SERIES

EBARA – Sump, Effluent, Sewage – DL SERIES

For Sump, Effluent, Wastewater and Sewage. A comprehensive range of Reliable, High quality Submersible pumps. Of robust Cast iron construction, with many designs features

  • Unique impeller design prevents overload under severe operation conditions
  • Semi-open non-clog impellers prevent pump clog by foreign matter.
  • The protective device built into the motor prevents the motor from damage as a result of over-current or abnormal temperature rise of the coil.
  • Optional quick discharge connector facilitates easy installation and maintenance
  • Range of models is up to 300mm discharge and up to 45kW available
  • Cutter type version

Brand:

Category:

EBARA – Sump, Effluent, Sewage – DL SERIES

Pumps

Model:

EBARA – Sump, Effluent, Sewage – DL SERIES

DL Series

Type:

EBARA – Sump, Effluent, Sewage – DL SERIES

Effluent / Sewage / Sump

Specifications

  • Capacities: up to 3100 gpm
  • Heads: deliver up to 148 feet
  • Max. submergence: up to 8 meters
  • Max. solid: up to 76 mm
  • Delivery port: up to 12″ npt discharge
  • Max. Temperature: 40*C
  • Motor rating: up to 40 hp- (60 hp for cutter type), 230/380/460V, three phase, 1800RPM, 60hz
